Groundnut Seed Digital Moisture Meter

Get a Price/Quote

MOQ : 1 Piece

Groundnut Seed Digital Moisture Meter Specification

Interface Type
Push-button operation

Features
Portable, automatic temperature compensation, user-friendly interface

Temperature
0C - 50C (operational)

Automation Grade
Semi-automatic

Display Type
Large digital LCD display

Response Time
Less than 10 seconds

Humidity
10% - 95% RH (operational)

Measuring Range
0% - 40%

Test Range
0%-40% moisture content

Port Size
Standard sample compartment

Mounting Type
Table top

Equipment Type
Digital Moisture Meter

Resolution
0.1%

Application
Groundnut seed moisture measurement

Frequency
50 Hz

Accuracy
0.2%

Power Supply
230V AC, 50 Hz

Specimen Size
5-20g groundnut seeds

Number of Specimens
1 at a time

Operating Voltage
230V AC

Usage
Moisture analysis of groundnut seeds

Capacity
Single sample per test

Machine Weight
1.5 kg (Approx.)

Test Speed
Manual operation (result in seconds)

Test Width
Suitable for standard seed samples

Test Stroke
N/A (non-applicable to moisture meters)

Control Mode
Microcontroller based digital system

Groundnut Seed Digital Moisture Meter Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Day

Delivery Time
4-5 Days

About Groundnut Seed Digital Moisture Meter

Groundnut Seed Digital Moisture Meter supplied by us is designed having a big hopper for adding test sample and a screen just below it. It operates on the principle of non-destructive method using a transducer which converts one form of energy into another form. This meter has a measuring range of 0% to 40% with testing time of only one minute. It has user-friendly operation and assures high durability with no maintenance requirement. Groundnut Seed Digital Moisture Meter needs only about 0.03 watts of power for working that can be provided by 4 pencil cells.

Technical Specifications

Application	Measuring Groundnut Seed/ Peanut Moisture Percentage
Accuracy	0.2 %
Brand	National Instruments (India)
Warranty	1 Year
Measuring Range	0 to 40%
Model	DMM_Groundnutseed
Size/Dimension	250 CC
Display Type	Digital
Analysis Time Approx	One sample per minute
Weight	Less than one Kg
Dimension	125H X 150W X 210D mms
Power	0.03 watts approx
Sensitivity	0.1%
Power Requirement	Four Pencil Cells
Power Consumption	0.03 Watts Approximately
Packaging Type	Box

Advanced Moisture Detection Technology

The device leverages capacitive/dielectric principles to measure moisture content non-destructively, ensuring groundnut seeds remain usable after testing. The system accommodates standard specimen sizes and employs a secure, top-loading mechanism, making sample handling both simple and efficient. Calibration options for multiple crops, including groundnuts, further enhance its versatility.

Precision and User-Friendly Operation

Equipped with a microcontroller-based digital control system, this moisture meter delivers results with exceptional accuracy (0.2%) within seconds. The large, easy-to-read digital LCD and push-button interface streamline the testing process, while digital alerts provide clear low/high moisture indications, reducing the risk of user error.

Portable and Durable Construction

Designed for field or laboratory usage, the meter weighs approximately 1.5 kg and is constructed with robust, non-corrosive stainless steel. It runs on 230V AC or an optional 9V batteryensuring flexibility for different environments. Its ISI and CE certification guarantee compliance with international safety standards.

FAQs of Groundnut Seed Digital Moisture Meter:

Q: How does the Groundnut Seed Digital Moisture Meter detect moisture content in seeds?

A: The device uses a capacitive or dielectric measurement principle, where the groundnut seeds are placed in a non-corrosive stainless steel sample cup. Changes in the dielectric constant, based on the moisture level in the sample, are measured accurately by the equipments microcontroller-based digital system.

Q: What is the process for testing groundnut seed moisture using this meter?

A: Simply load 520g of groundnut seeds into the secure, top-loading sample cup. Close the lid, select the desired crop calibration, and press the start button. The meter delivers accurate moisture readings within seconds on a large digital LCD display, accompanied by digital alerts for low or high moisture levels.

Q: When should I use this digital moisture meter for groundnut seeds?

A: It is best used before storage, processing, or packaging of groundnut seeds to ensure optimal moisture levels and prevent spoilage. Regular monitoring supports consistently high product quality and reduces post-harvest losses.

Q: Where can this moisture meter be effectively used?

A: The moisture meter is suitable for both laboratory and field environments, thanks to its portable design and robust construction. It is ideal for exporters, manufacturers, and suppliers within India who require accurate groundnut moisture assessment.

Q: What are the main benefits of using this digital moisture meter?

A: Benefits include rapid and non-destructive moisture analysis, high measurement accuracy, user-friendly operation, multi-crop calibration, portable design, and automatic temperature compensation. Its safety certifications ensure reliable, long-term use in diverse operational conditions.

Q: How is the equipment powered, and what are its operating conditions?

A: The meter operates on 230V AC, 50 Hz, with an optional 9V battery for added flexibility. It functions reliably in environments with 10%95% relative humidity and temperatures from 0C to 50C.
